MDVCI Maserati Detector Support Programming and Diagnosis with Maintenance Data Installed on Panasonic CF19 Ready to Use MDVCI Maserati Detector Description:
Maserati Diagnosis Vehicle Communication Interface. MDVCI of Maserati Diagnostics System is an electronic device for the diagnostics of electronic control units (ECU) installed in modern vehicles. It's cover Maserati from 1995 year (Ghibli and Quattroporte) 3200GT, 4200 from MY2002-MY2006, Qauttroporte and gran tourismo from 2004 till 2016.
The New Maserati Diagnostic Tester System is a Panasoinc CF laptop device. It is also equipped with:
Standard RS232C serial lines x 3
Standard ISO9141 / CARB / KEYWORD 2000 serial lines x 6
Standard CAN serial lines x 2
Multimeter in volts (up to 200 V d.c.) and Ohm (up to 1 Mohm)
Maserati Diagnosis Tester can be interfaced to a PC containing the software required to update the ECU diagnostics software throughone of the following lines:
Standard RS232C serial line
USB serial line
Ethernet 10/100Mbit network
Ethernet Wireless 802.11b network
For better efficiency and faster data transfer between the PC and the DEIS unit, we suggest you use the USB line or an Ethernet/Wireless network for communications.
MDVCI of Maserati Diagnostics System Languages: Italian,Spanish,French,English,German
MDVCI of Maserati Diagnostics System Support ModelCover SD2 / SD3 Until 20163200 GT (3200 GT)Ghibli (M157)Gransport (Gransport)GranTurismo (M145)GT (M138)Quattroporte (M139)Quattroporte (M156)Quattroporte MY (M139 MY)Software figures shown as follows:
MDVCI Maserati Detector Package including:
1pc x The Host
2pc x OBDII Cable
1pc x USB Cable
1pc x The power supply
1pc x New PANASONIC CF19
